Following user requests for a larger matrix version of the XP-Relay, CB Electronics has designed three larger units of the digitally controlled relay patchbay.
The XP-Relay32 / 32X and 64 is a state of the art, software-controlled relay patchbay that seamlessly integrates with professional audio setups, offering pristine, relay-based signal routing with zero compromise, a transparent audio path, controlled via the intuitive feature rich XPatch4 APP, extensive connectivity, scalable configurations, and robust reliability without generating heat or requiring a fan.
Allowing you to do creative things you never would have done with a traditional patchbay. Switch from Tracking to Mixing with one click, A/B up to 4 paths, and so much more!
Uncompromising Signal Path
A patchbay must route audio with absolute transparency, and XP-Relay achieves this through an extensive matrix of high-quality relays, ensuring the signal path remains as pure as a direct cable connection. The relay-based switching system ensures the routing process does not affect the integrity of the signal, making it ideal for demanding studio environments.
Intelligent Software Control for Seamless Connectivity and Control
XP-Relay is configured and managed by the intuitive XPatch4 App available for Windows and macOS. The XPatch4 APP controls up to four XP-Relay or XPatch units via USB, or Ethernet. XPatch4 allows effortless creation and management of complex routing chains, including mults, mono-to-stereo conversions, inserts, signal processors, and AB groups.
Users can save and recall configurations instantly, enabling real-time adjustments, preset configuration, and storage of routing setups. Streamlining workflow and ensuring session continuity. By treating hardware audio processors like digital plugins, XP-Relay enables users to drag and drop devices in sophisticated routing chains that can be edited, auditioned, and recalled at any time. Once configured, the last-used routing loads instantly upon power-up, minimising downtime and maximising efficiency.
Advanced Relay Technology
Utilising telecom-grade relay technology rated for millions of cycles, XP-Relay ensures long-term reliability and ultra-low power consumption. The absence of active electronics in the signal path allows for the transmission of mic-level sources, phantom power, control voltage, digital audio, and MIDI without degradation. Routing changes are confirmed by the soft click of a physical relay, providing immediate feedback.
Versatile I/O and Expandability
The rear panel features DB25 connectors offering 32×32, 32×32 Upgradeable to 64×64, and 64×64 channels of input and output, while the front panel includes 2 XLR/TRS combi jacks inputs, and 2 XLR Outputs for quick auditioning of equipment.
Link up to 4 units together using the DB25’s and set up as Send / Returns for larger systems.
Optimised Workflow and Studio Integration
Designed to eliminate the interruptions associated with manual patching, XP-Relay ensures fluid session transitions and uninterrupted creativity. It operates silently and requires no cooling fans, making it a direct replacement for conventional patchbays.
It integrates effortlessly with large-scale TT patchbay systems by connecting your existing patchbays to one or more of the rear DB25’s for a truly versatile scalable solution for professional studios requiring advanced routing capabilities.
XP-Relay redefines the functionality of an analog patchbay, combining relay-based precision with intuitive software control to deliver a state of the art routing solution for modern studios.
The XP-Relay32 (£3,200 GBP ex. VAT) is scheduled to ship in August 2025, while the XP-Relay32X (£3,270 GBP ex. VAT) and XP-Relay64 (£7,000 GBP ex. VAT) are scheduled for October 2025. Customers can pre-order the units at a 10% discount by ordering before the 1st of the month that the units ship.
More information: CB Electronics
